Introduction

This notebook gives a practical guide to inspire developers and researchers in building AI applications. Through a hands-on example of creating a multimodal RAG (Retrieval Augmented Generation) system for scientific papers, we’ll explore:

How to leverage Large Language Models (LLMs) hosted on Nscale serverless platform

The fundamentals of building effective RAG systems

While we’ll be building a specific implementation for processing arXiv papers, the concepts and patterns demonstrated here can be adapted to create various AI services and applications.

Whether you’re looking to understand RAG systems, explore multimodal AI, or learn how to utilize Nscale’s hosted LLMs effectively, this notebook provides a foundation to build upon.

You can access the Jupyter Notebook version here, where you can explore and execute the code yourself.

​

Outlines of a simple RAG

If you are not familiar with RAG, it is a technique that enhances AI language models by first retrieving relevant information from a knowledge base, then using that context to generate more accurate and informed responses. Think of it as giving an AI model access to a specialized library that it can reference before answering questions. Here’s the outline of a simple RAG workflow:

1. Indexing phase:
   1. The user first uploads a document
   2. The document’s content is then split into chunks
   3. Those chunks are fed to an embedding model that will convert the text to a vector of number that captures the sementic meaning of the chunk
   4. The chunk is then stored in a vector store or database
2. Retrieval phase:
   1. The user will query the system
   2. The query itself will be converted to an embedding
   3. A vector similarity search between the query vector and the vectors stored in the database then happens.
3. Generation phase:
   1. Once the vectors are retrieved, we use a large language model to generate a response based on the query and the retrieved context.

​

Multimodal RAG

While simple RAGs can work well, they often fall short in tasks that requires parsing complex layouts. For example scientific paper, are complex to parse because of their sometimes difficult structure which can include text, image and tabular data.

One solution has been to leverage projects such as LlamaParse or unstructured.io to parse those documents using OCR, layout detection and captioning. Such approach can work well but will lead to overhead time in the indexing phase as seen in the following figure from ColPali: EFFICIENT DOCUMENT RETRIEVAL WITH VISION LANGUAGE MODELS by Faysse et al.

Therefore in this notebook we will explore an efficient and simpler approach to building a multimodal RAG using the VLM ColPali. In high level, ColPali is based of PaliGemma-3B a vision language model that is further enhanced to generate ColBERT-style multi-vector representations of text and image data, among other optimisations. The model directly encode pages and can be used for multimodal retrieval tasks.

To achieve the multimodal RAG system for scientific papers we are going to combine two powerful models:

Llama 4 Scout for it’s vision capability, it is hosted on Nscale serverless

ColPali a VLM model capable of generating accurate embeddings of image data.

If the concept is not clear by now, do not worry as we will be building a simple multimodal RAG system to answer any questions related to ColPali.

Now let’s get started!

​

Implementation

​

Install the required libraries

!pip install arxiv # arXiv API
!pip install byaldi # RAG model
!pip install pdf2image # Convert pdf to images
!pip install openai # LLM

Install poppler
!sudo apt-get install -y poppler-utils

​

Export the necessary variables

nscale_api_key = "xxxx"

​

Retrieve the arXiv data

If you haven’t heard of arXiv, in brief it’s an open-access repository where researchers share preprints of scientific papers before formal peer review, primarily in fields like physics, mathematics, and computer science.

For our use case we will use the paper “ColPali: EFFICIENT DOCUMENT RETRIEVAL WITH VISION LANGUAGE MODELS” by Faysse et al.

And leverage arxiv’s API to retrieve the paper.

# Search for the most relevant paper on ColPali and download it to our data folder.

import arxiv
import os

search = arxiv.Search(
        query="ColPali",
        max_results=1,
        sort_by=arxiv.SortCriterion.Relevance,
    )

results = list(search.results())
paper = results[0]

download_dir = "data"

pdf_path = os.path.join(download_dir, f"{paper.get_short_id()}.pdf")
paper.download_pdf(filename=pdf_path)

​

Initialise the multimodal model

We are going to initialise ColPali model using the byaldi library. ColPali will be used to generate the embeddings of the document. It does so by converting the document into images that will then be cut into patches, these patches are later embedded in a 128 dimension vector space.

ColPali: EFFICIENT DOCUMENT RETRIEVAL WITH VISION LANGUAGE MODELS by Faysse et al.

​

Indexing phase

from byaldi import RAGMultiModalModel

# Initialise the multimodal model
retrieval_model = RAGMultiModalModel.from_pretrained("vidore/colpali-v1.3")

# Index the data

retrieval_model.index(
    input_path="data/", index_name="image_index", store_collection_with_index=True, overwrite=True
)

​

Initialise LLM

We will use the new Llama 4 Scout as LLM, it is a 17 billion active parameter model with 16 experts that uses a mixture-of-experts (MoE) architecture. It’s a very powerful multimodal model with native multimodality, strong performance and an extremely large context window.

Running such model locally is not feasiable. For this reason we will be inferencing the model through Nscale serverless! Nscale offers 5$ of free credit upon signup, way more than enough to fully understand the ColPali paper!

​

Retrieval and generation phase

from openai import OpenAI

# Initilise the client
nscale_base_url = "https://inference.api.nscale.com/v1"

client = OpenAI(
    api_key=nscale_api_key,
    base_url=nscale_base_url
)

# Query the retrieval model on the ColPali paper

query = "Describe the results of table 2"
returned_page = retrieval_model.search(query, k=2)[0].base64

response = client.chat.completions.create(
  model="meta-llama/Llama-4-Scout-17B-16E-Instruct",
  messages=[
    {
      "role": "user",
      "content": [
        {"type": "text", "text": query},
        {
          "type": "image_url",
          "image_url": {
          },
        },
      ],
    }
  ],
  max_tokens=300,
)

print(response.choices[0].message.content)

​

Conclusion

In this notebook, we’ve successfully built a multimodal RAG system for scientific papers that combines:

• ColPali’s powerful document retrieval and embedding generation
• Llama 4 Scout’s advanced vision-language understanding, accessed through Nscale’s serverless platform

We demonstrated how to:

1. Download and process arXiv papers
2. Index documents using ColPali’s multimodal capabilities
3. Perform intelligent retrieval based on user queries
4. Generate contextual responses using Llama 4 Scout

​

What We’ve Learned

• How to implement a multimodal RAG system without complex OCR pipelines
• Ways to leverage Nscale’s LLMs effectively
• Techniques for handling both text and visual content in academic papers

​

Build Your Own

This implementation serves as a starting point - here are some ways you could extend it:

• Adapt the system for other document types (patents, technical documentation, etc.)
• Add more sophisticated indexing, retrieval and generation strategies
• Implement concurrent processing for large document collections
• Create a web interface or API
• Fine-tune the models for your specific use case

Remember, the patterns shown here can be adapted for various use cases - from document analysis to building complete AI services. Happy building! 🚀
